metal briquetting machine

A multifunctional hydraulic packaging machine

Metal compactor, iron wire aluminum profile corner material packaging machine, supports customization, is a multi-purpose waste metal compactor (packaging machine). The metal is compressed and packaged to reduce volume, making it easy to load and box, and more importantly, to improve the melting rate.

Get a free quote

Phone/WhatsApp contact

In the global metal recycling industry, the Metal Briquetting Machine has emerged as a revolutionary technology, transforming fragmented metal waste into high-density, transportable briquettes. This equipment addresses critical challenges in resource conservation, logistics optimization, and environmental protection by compressing loose metal scraps—such as steel shavings, aluminum chips, copper filings, and even entire car shells—into compact blocks without additives or heating. Its applications span steel mills, automotive dismantling plants, and non-ferrous metal smelters worldwide, driving circular economy practices across continents.

Horizontal metal briquetting machine operation video

Name	Metal Briquette Machine	Applicable scope	Steel mills, recycling and processing industries
Driving method	Hydraulic or diesel	Control system	Fully automatic (PLC control panel)

What is a metal briquetting machine

The metal chip pressing machine can directly cold press powdered cast iron chips, steel chips, copper chips, aluminum chips, high-quality mineral powder, etc. into cakes for storage, transportation, and furnace recycling and reuse. After being compressed into blocks, the loss for recycling in the furnace is extremely low. The entire production process does not require heating, additives, or other processes, and is directly cold pressed into shape, ensuring that the original material remains unchanged while forming. For example, using cast iron filings instead of cast pig iron after forming. For castings made of special materials, recycling has greater significance.

• Target Materials: Bulky scrap (e.g., car bodies, steel beams, aluminum cans, oil drums).
• Versatile Shaping: Produces cubes, cylinders, or octagons for optimized furnace charging.
• High Throughput: Processes 5–50 tons/shift, with dual-ram models handling mixed-material streams.
• Mobility: Diesel-powered variants operate in remote areas without grid access.

Metal Scrap Briquetting Machine Product Features

1. All models of metal packaging machines are hydraulic driven (or diesel driven);
2. Scrap metal briquetting machine：The discharge form of the machine body can be selected through different methods such as flipping, pushing, or manual pickup;
3. hydraulic baler：Easy to install, without the need for foot fixation, diesel engines can be used for power in areas without power supply;
4. There are ten levels of extrusion pressure from 63 tons to 400 tons for users to choose from, with production efficiency ranging from 5 tons per shift to 50 tons per shift;

Global Market Trends

• Asia-Pacific Dominance: China and India account for 45% of global production, driven by infrastructure booms and automotive manufacturing.
• European Precision: German and Italian manufacturers lead in high-end models, exporting to 60+ countries with 98% customer satisfaction rates.
• North American Demand: The U.S. recycling sector invests $200 million annually in briquetting tech to meet EPA emissions standards.

Product Features of Metal Forming Machines

1. Hydraulic metal chip pressing machine is mainly used to press various metal chips (iron chips, copper chips, aluminum chips, etc.), powdery metal powder (iron powder, aluminum powder, copper powder, lead powder, etc.), smelting additives, sponge iron, etc. into high-density cylindrical cake blocks (weighing 2-8 kilograms) without adding any adhesive. The cake block density can reach 5T/M3 or above (the density of the pressed cake blocks varies depending on the raw material). The pressed cake blocks can be directly put into the furnace for use, and the cast iron grade can reach HT200-250, saving costs of about 700 yuan per ton of casting.
2. Forming machine metal：Adopting advanced hydraulic transmission technology and high-quality wear-resistant oil seals, the oil cylinder is processed and assembled using the latest high-tech technology in China, ensuring continuous operation without reducing cylinder pressure, durability, and smooth operation; Computer control, high degree of automation, low failure rate, easy maintenance, etc.

Aluminum chip metal briquette machine is widely used

Hydraulic packaging machines can extrude various metal waste materials (such as scraps, shavings, scrap steel, scrap aluminum, scrap copper, scrap stainless steel, scrap cars, etc.) into qualified furnace materials in various shapes such as rectangular, octagonal, cylindrical, etc. This can not only reduce transportation and smelting costs, but also improve furnace feeding speed.

Metal forming machine manufacturers：Steel mills, recycling and processing industries, non-ferrous and ferrous metal smelting industries, and renewable utilization industries

Metal briquetting machine product parameters

Model	Nominal thrust (KN)	Size of pressure box （mm）	Packaging block size （mm）	Package weight （Kg）	Yield （t/h）	Power allocation （Kw）
63	630	1000*600*500	190*190	15~30	0.4~0.8	7.5
100	1000	1000*700*550	230*230	30~40	0.6~1.2	11
125	1250	1200*700*600	300*300	60~80	1.2~1.5	15
135	1350	1400*600*600	600*240	50~75	1.5~2.8	22
160	1600	1600*1000*800	400*400	110~150	2.2~3.0	22
200	2000	1800*1400*900	450*450	210~300	3.0~5.0	22*2
250	2500	2000*1750*1000	500*500	250~280	5.0~6.3	22*2
315	3150	2500*2000*1200	500*500	250~360	4.0~6.5	37*2
400	4000	3000*2000*1200	500*600	250~380	6.8~8.0	45*2

Hydraulic metal briquetting machine for sale

Hydraulic metal briquetting machine price：On site feedback photos of customers from different regions suppressing different materials

How to choose a Metal Briquette Machine

When choosing a metal scrap iron compactor, attention can be paid to the material, process, structural design, and other aspects of the product, as well as whether there is a professional research and development team and technical support. Choose the appropriate equipment to increase the density of metal waste, reduce its occupancy space, and reduce storage and transportation costs. At the same time, pay attention to the reliability and durability of the equipment, as well as the maintenance costs in the later stage. Suitable models can be customized according to one’s own budget and actual needs.

Material Type:

• Fine chips → Briquetting machine with de-oiling system.
• Mixed scrap → Horizontal baler with magnetic separators.

Production Volume:

• Small workshops: 20–100-ton vertical balers.
• Industrial plants: 500–1,500-ton horizontal balers.

Regulatory Compliance:

• Ensure machines meet CE (EU), UL (US), or ISO 14001 standards.

After-Sales Support:

• Prioritize suppliers offering 24/7 technical support and spare parts within 48 hours.

metal briquete machin：Loading and shipping

Hydraulic metal baler factory，The factory arranges different logistics vehicle sizes according to the customized machine models and sizes of different customers, ensuring timely delivery and reliable transportation

Metal balers and briquetting machines are not just machinery—they’re strategic assets for businesses aiming to thrive in a circular economy. By turning waste into high-value feedstock, these machines help manufacturers cut costs, meet sustainability targets, and tap into lucrative recycling markets.
